Biomedical Lab Equipment List

• Name: High Density EEG System
• Manufacturer: ANT Neuro with Wet EEG Electrodes
• Description: 64 channels, 500 Hz sampling frequency

• Name: NIRSport2
• Manufacturer: NIRX
• Description: Mobile fNIRS System, 8 sources and 8 detectors, 10.17 Hz Sampling frequency

• Name: EyeLink 1000
• Manufacturer: SR Research Ltd
• Description: Eyetracker, USB camera, 1000 Hz Sampling frequency

• Name: eego sports
• Manufacturer: ANT Neuro with Dry Electrodes
• Description: 64 channels, Up to 2048 Hz sampling frequency

• Name: DSI-7
• Manufacturer: Wearable Sensing
• Description: a research-grade wireless dry electrode EEG headset, capable of VR experiments

SP-200, Biologic Potentiostat

A sample of flexible polymer-based electrodes developed by our group

Flexible implantable electrodes to restore motor function after peripheral nerve injuries

The potentiostat/Galvanostat (Biologic-VSP-200 and EC lab. software) is a powerful and versatile equipment used in our laboratories to fully assess the electrochemical properties of flexible electrodes. In our group, the potentiostat is used to evaluate the electro-chemical performance of the developed flexible electrodes in terms of impedance, electrochemical stability (cyclic voltammetry measurements), and charge storage capacity among other parameters, thereby, giving us a full overview of the potential of the material as a future implantable electrode.

Background:

Injury to peripheral nerves that connect the central nervous system to effector muscles can result in irreversible atrophy and loss of the muscle due to lack of stimulation by nerves. Electrodes based on expensive noble metals and metal alloys have been used to stimulate muscles and prevent their atrophy during the peripheral nerve regeneration period. However, those harsh metallic electrodes suffer from limitations mainly their mechanical mismatch with the soft biological tissues.

Objectives:

This project aims to develop novel low-cost and flexible electrodes based on polymers for future implantable purposes including tissue stimulation and/or signal recording.

Methods:

In our group at AUS, electrode fabrication, structural, electrochemical, and mechanical characterizations, stability testing, and in vitro biocompatibility of the electrodes is performed. Furthermore, surface signal measurements such as electrocardiography and electromyography using the electrodes is performed to assess their potential as signal recording electrodes.

• Cortisol Saliva ELISA Kit
• Deep Freezer @-30 degrees C
• Cocoro meter by Nipro Cooperation
• Powerlab physiological measurement system
• Programmable filter
• Pico Ammeter
• Patient simulators
• Electrical safety analyzer
• Various measuring instruments such as digital mustimeters, digital storage oscilloscopes, DC power supplies, function generators, digital stopwatches and breadboards
• Sensors to measure ECG, EEG, GSR, SPiO2, temperature, blood pressure, heart and respiratory rates
